• Size -   8mm-50mm    • Material - Carbon Steel, Stainless steel    • Surface - Galvanized, ungalvanized    • Technology - Laid

   • T/S: 1670/ 1770/ 1870 N/MM2    • Structure - 6X19 6x37 6x36

The 6 x 37 classification of wire rope includes most 6 strand , round strand ropes having 27 to 49 wires per strand. While 6 x 19 ropes give primary emphasis to abrasion resistance in varying degrees, the 6 x 37 ropes are important for their fatigue resistance. This fatigue resistance is made possible by the greater number of small wires per strand. Because of this emphasis on fatigue resistance the problem of choice within the 6 x 37 classification is greatly reduced. Although there are exceptions for special applications, the constructions in the 6 x 37 classifications are primarily designed to be the most efficient for each rope diameter. As the rope size increases, for instance, a large number of wires can be used to achieve required fatigue resistance and still those wires will be large enough to offer adequate resistance to abrasion. In sizes over 2 inches the 6 x 49 SWS would be so small that their resistance to abrasion would be a problem.

It should be noted that the greater number of wires makes the
6 x 37 classification more susceptible to crushing. This however,
can frequently be overcome by an independent wire rope core
and the use of well designed sheaves and grooved drums

6x19+IWS（7x19 ）Galvanized aircraft cable is preferred when strength and high flexibility are needed. The construction includes 7 strands with 19 wires per strand in galvanized steel, creating a strong steel cable that is both flexible and resistant to corrosion. This aircraft cable offers an enormous range of applications including agriculture,zip lines, sign and banner.


• Material: Bao Steel, Sha Steel, High Carbon Steel #60 #70 #80
• Dia: 6mm-50mm
• Lay Direction - Right Hand Regular Lay, Left Hand Regular Lay
• Surface - Galvanized, ungalvanized
• Tensile of Strength: 1770mpa 1870mpa 1960mpa 2160MPa
• Construction - 6x19+IWS（7x19)

• Delivery Time - Within 30 days after got the payment

• Payment Terms - T/T, L/C, D/P, Western Union

6x19S construction is a wire rope construction with superb breaking load characteristics and is used in a wide range of applications, available with both FC (fibre core) and IWRC (independent wire rope core). The construction has proved particularly popular for applications where the additional resistance to wear and abrasion provided by the larger outer wires is superior to the other 6x19 constructions.      • Size -   6mm-22mm    • Material - Carbon Steel    • Surface - Galvanized    • Technology - Laid    • Structure - 6X19S

The 6 x 37 classification of wire rope includes most 6 strand , round strand ropes having 27 to 49 wires per strand. While 6 x 19 ropes give primary emphasis to abrasion resistance in varying degrees, the 6 x 37 ropes are important for their fatigue resistance. This fatigue resistance is made possible by the greater number of small wires per strand. Because of this emphasis on fatigue resistance the problem of choice within the 6 x 37 classification is greatly reduced. Although there are exceptions for special applications, the constructions in the 6 x 37 classifications are primarily designed to be the most efficient for each rope diameter. As the rope size increases, for instance, a large number of wires can be used to achieve required fatigue resistance and still those wires will be large enough to offer adequate resistance to abrasion. In sizes over 2 inches the 6 x 49 SWS would be so small that their resistance to abrasion would be a problem.

It should be noted that the greater number of wires makes the
6 x 37 classification more susceptible to crushing. This however,
can frequently be overcome by an independent wire rope core
and the use of well designed sheaves and grooved drums

6x19+IWS（7x19 ）Galvanized aircraft cable is preferred when strength and high flexibility are needed. The construction includes 7 strands with 19 wires per strand in galvanized steel, creating a strong steel cable that is both flexible and resistant to corrosion. This aircraft cable offers an enormous range of applications including agriculture,zip lines, sign and banner.


• Material: Bao Steel, Sha Steel, High Carbon Steel #60 #70 #80
• Dia: 6mm-50mm
• Lay Direction - Right Hand Regular Lay, Left Hand Regular Lay
• Surface - Galvanized, ungalvanized
• Tensile of Strength: 1770mpa 1870mpa 1960mpa 2160MPa
• Construction - 6x19+IWS（7x19)

• Delivery Time - Within 30 days after got the payment

• Payment Terms - T/T, L/C, D/P, Western Union

This compacted wire rope construction is available in both galvanised and ungalvanised finish with either ordinary or langs lay. The construction family includes 17X7, 18X7 and 19X7. For further flexibility and other performance characteristics we also supply 32X7, 35X7 and 37X7.       • Size -   3mm-50mm    • Material - Carbon Steel     • Surface - Bright(ungalvanized), Galvanized, stainless, PVC or Grease    • Technology - Right regular lay, Left regular lay, Right lang lay, Left lang lay    • Structure - 18*7 19*7

The 6 x 37 classification of wire rope includes most 6 strand , round strand ropes having 27 to 49 wires per strand. While 6 x 19 ropes give primary emphasis to abrasion resistance in varying degrees, the 6 x 37 ropes are important for their fatigue resistance. This fatigue resistance is made possible by the greater number of small wires per strand. Because of this emphasis on fatigue resistance the problem of choice within the 6 x 37 classification is greatly reduced. Although there are exceptions for special applications, the constructions in the 6 x 37 classifications are primarily designed to be the most efficient for each rope diameter. As the rope size increases, for instance, a large number of wires can be used to achieve required fatigue resistance and still those wires will be large enough to offer adequate resistance to abrasion. In sizes over 2 inches the 6 x 49 SWS would be so small that their resistance to abrasion would be a problem.

It should be noted that the greater number of wires makes the
6 x 37 classification more susceptible to crushing. This however,
can frequently be overcome by an independent wire rope core
and the use of well designed sheaves and grooved drums

The 6 x 37 classification of wire rope includes most 6 strand , round strand ropes having 27 to 49 wires per strand. While 6 x 19 ropes give primary emphasis to abrasion resistance in varying degrees, the 6 x 37 ropes are important for their fatigue resistance. This fatigue resistance is made possible by the greater number of small wires per strand. Because of this emphasis on fatigue resistance the problem of choice within the 6 x 37 classification is greatly reduced. Although there are exceptions for special applications, the constructions in the 6 x 37 classifications are primarily designed to be the most efficient for each rope diameter. As the rope size increases, for instance, a large number of wires can be used to achieve required fatigue resistance and still those wires will be large enough to offer adequate resistance to abrasion. In sizes over 2 inches the 6 x 49 SWS would be so small that their resistance to abrasion would be a problem.

It should be noted that the greater number of wires makes the
6 x 37 classification more susceptible to crushing. This however,
can frequently be overcome by an independent wire rope core
and the use of well designed sheaves and grooved drums

 This product is equal laid rope. The index of metal filing is high. The strand structure is tight. When the steel wire rope is underworking, the contact stress between wires is small and no secondary bending stress and the contact area between steel wire rope and pulleygroove is large, so the this steel wire rope has characters of wear resistance, fatigue resistance, anti-extrusion performance and easily deformed. Features: The contact between wires is equal laid. The strands of rope are spiral surface contact When the steel wire rope is loading, thecontact stress between strands is small, and then the service life is correspondingly longer. Wire interactive twisted, and then the backwashforce is small.      • Size -   8mm-40mm    • Material - Carbon Steel    • Surface - galvanized or ungalvanized    • Technology - Laid    • Structure - 4VX39S+5FC
