This compacted wire rope construction is available in both galvanised and ungalvanised finish with either ordinary or langs lay. The construction family includes 17X7, 18X7 and 19X7. For further flexibility and other performance characteristics we also supply 32X7, 35X7 and 37X7.       • Size -   3mm-50mm    • Material - Carbon Steel     • Surface - Bright(ungalvanized), Galvanized, stainless, PVC or Grease    • Technology - Right regular lay, Left regular lay, Right lang lay, Left lang lay    • Structure - 18*7 19*7

The 6 x 37 classification of wire rope includes most 6 strand , round strand ropes having 27 to 49 wires per strand. While 6 x 19 ropes give primary emphasis to abrasion resistance in varying degrees, the 6 x 37 ropes are important for their fatigue resistance. This fatigue resistance is made possible by the greater number of small wires per strand. Because of this emphasis on fatigue resistance the problem of choice within the 6 x 37 classification is greatly reduced. Although there are exceptions for special applications, the constructions in the 6 x 37 classifications are primarily designed to be the most efficient for each rope diameter. As the rope size increases, for instance, a large number of wires can be used to achieve required fatigue resistance and still those wires will be large enough to offer adequate resistance to abrasion. In sizes over 2 inches the 6 x 49 SWS would be so small that their resistance to abrasion would be a problem.

It should be noted that the greater number of wires makes the
6 x 37 classification more susceptible to crushing. This however,
can frequently be overcome by an independent wire rope core
and the use of well designed sheaves and grooved drums

 This product is equal laid rope. The index of metal filing is high. The strand structure is tight. When the steel wire rope is underworking, the contact stress between wires is small and no secondary bending stress and the contact area between steel wire rope and pulleygroove is large, so the this steel wire rope has characters of wear resistance, fatigue resistance, anti-extrusion performance and easily deformed. Features: The contact between wires is equal laid. The strands of rope are spiral surface contact When the steel wire rope is loading, thecontact stress between strands is small, and then the service life is correspondingly longer. Wire interactive twisted, and then the backwashforce is small.      • Size -   8mm-40mm    • Material - Carbon Steel    • Surface - galvanized or ungalvanized    • Technology - Laid    • Structure - 4VX39S+5FC

Product Features • Excellent ruggedness

• Crush resistance

• Abrasion resistance

• Good combination of flexibility and wear resistance

• Mostly used as governor rope Product Features Dia - 5mm-60mm

• Tensile strength: 1670Mpa; 1770Mpa; 1870Mpa • Surface - Galvanized or Ungalvanized • Lay direction - RHO (Right hand ordinary lay)
LHO (Left hand ordinary lay)
RHL (Right hand Langs lay)
LHL (Left hand Langs lay)

Product Features • Excellent ruggedness

• Crush resistance

• Abrasion resistance

  Product Features Dia - 5mm-60mm

• Tensile strength: 1670Mpa; 1770Mpa; 1870Mpa • Surface - Galvanized or Ungalvanized • Lay direction - RHO (Right hand ordinary lay)
LHO (Left hand ordinary lay)
RHL (Right hand Langs lay)
LHL (Left hand Langs lay)

Quick Details • Size - 5mm-60mm • Material - Carbon Steel • Surface - Galvanized • Technology - Laid • Structure - All Type structure for wire rope Product Features • Extra life due to high quality galvanization

• Special lubricant for superior corrosion resistance



Product Features • Excellent ruggedness

• Crush resistance

• Abrasion resistance

• Good combination of flexibility and wear resistance

• Mostly used as governor rope Product Features Dia - 5mm-60mm

• Tensile strength: 1670Mpa; 1770Mpa; 1870Mpa • Surface - Galvanized or Ungalvanized • Lay direction - RHO (Right hand ordinary lay)
LHO (Left hand ordinary lay)
RHL (Right hand Langs lay)
LHL (Left hand Langs lay)

Quick Details • Size - 5mm-60mm • Material - Carbon Steel • Surface - Galvanized • Technology - Laid • Structure - All Type structure for wire rope Product Features • Extra life due to high quality galvanization

• Special lubricant for superior corrosion resistance

• Steel core for increased strength

Product Features • Excellent ruggedness

• Crush resistance

• Abrasion resistance

• Good combination of flexibility and wear resistance

• Mostly used as governor rope Product Features Dia - 5mm-60mm

• Tensile strength: 1670Mpa; 1770Mpa; 1870Mpa • Surface - Galvanized or Ungalvanized • Lay direction - RHO (Right hand ordinary lay)
LHO (Left hand ordinary lay)
RHL (Right hand Langs lay)
LHL (Left hand Langs lay)

Quick Details • Dia - 5mm-60mm

• Tensile strength: 1670Mpa; 1770Mpa; 1870Mpa • Surface - Galvanized or Ungalvanized • Lay direction - RHO (Right hand ordinary lay)
LHO (Left hand ordinary lay)
RHL (Right hand Langs lay)
LHL (Left hand Langs lay)   Product Features • Better Abrasion Resistance

• Better Crush Resistance


Product Features • Excellent ruggedness

• Crush resistance

• Abrasion resistance

• Good combination of flexibility and wear resistance

• Mostly used as governor rope Product Features Dia - 5mm-60mm

• Tensile strength: 1670Mpa; 1770Mpa; 1870Mpa • Surface - Galvanized or Ungalvanized • Lay direction - RHO (Right hand ordinary lay)
LHO (Left hand ordinary lay)
RHL (Right hand Langs lay)
LHL (Left hand Langs lay)
